Breadboarding in the morning sun

A friend’s comparison build works perfectly, and attention turns to breadboarding the AT-314 VCF while the tempcos are still in transit.

2017-08-02 AT-314 breadboard

My friend Mike finished the comparison build, and it works perfectly.

Now patiently awaiting the arrival of the tempco resistors, and breadboarding the AT-314 VCF.

Breadboard of the AT-314 VCF in morning sunlight
The AT-314 VCF taking shape on the breadboard.
Close-up of the AT-314 breadboard
Morning-sun close-up of the breadboard work.
